Characteristics:
Conform with Intelsat, Eutelsat Requirements;
Carbon fiber reflector, high strength, light weight;
Good cross polarization, low sidelobe, high efficiency;
Dismounting& adjustment, convenient and quick;
Adopt the "Three-proof " measures, modern production process, meet various field work environment;
|
Model
|
NS-FAK-120
|
|
Operating Frequency GHz
|
Ka band
|
|
Receive
|
Transmit
|
|
18.7～20.2GHz
|
29.0～30.0GHz
|
|
Antenna gain dBi
|
≥44.0dBi@20.20GHz
|
≥47.4dBi@30.00GHz
|
|
Polarization
|
Circular
|
|
Antenna diameter
|
1.0m
|
|
Antenna type
|
Center feed
|
|
Material
|
Carbon fiber
|
|
Antenna weight
|
Net weight ≤25Kg (without BUC, LNB,package)
|
|
Antenna package
|
Aviation package box 1: 850×540×290
Aviation package box 2: 950×580×345
|
|
Antenna travel range
AZ
EL
Pol
|
360°
0°～90°
±90°
|
|
Antenna drive mode
|
Automatic
|
|
Working wind speed
|
≤11 m/s
|
|
Survival wind speed
|
≤18 m/s
|
|
Working temperature
|
-40℃～60℃
|
|
Storage temperature
|
-50°C～70°C
|
|
Humidity
|
≤95%（20 °C）
|
|
Protection level
|
IP65
|
|
